OptimStor - NextGen Secure NAS
Donation protected
We are engaged in building the Next Generation Secure Gateway / Firewall / NAS and Wireless AP device based on a secure virtual environment, that will provide the Home / SOHO and Enterprise clients with the security and storage requirements and features that fit their needs. Including Vault, a tool for securely accessing secrets. A secret is anything that you want to tightly control access to, such as API keys, passwords, certificates, Bitcoin wallets and more.
How many devices do you have around the house? A cable or DSL router? A wireless device you bought? Maybe a USB hard drive for backups? A Multimedia Center? Our purpose is to converge all this into one device including a Secure Firewall, Virtualization Capabilities, Storage for Backups, Multimedia Capable All-in-one Appliance for the Home, or a system designed for the road warrior on the go.
Tired of the same old over priced products built for the 90s ? Missing the features that are required for todays market? Whannabe NAS boxes or copycats that all look the same and have the same feature sets.
Visit optimcloud.com to see more
Designed to be a storage system, with a virtual Firewall/Gateway for protection, and various NAS capabilities amongst other features that you want and need not found in whats available from other vendors today.
Primarily NFS and S3 capabilities, along with virtualization technologies that make it a very flexible device, compact, cloud compatible and secure
Available for pre-order soon! OptimStor - The next generation of virtualized secure NAS / S3...
Heres the SDL file view for the Road Warrior version, a thin portable all in one secure gateway firewall / NAS / backup device. Design to be portable enough to fit in your laptop bag and light enough to not push you over the carry-on weight limits.
for the OptimStor XS 3D printed case, To be our smaller portable road warrior version. Secure and protect your data and communications while on the road with a Firewall/Storage/Virtualization all-in-one appliance.
Our Enterprise Version is a HA design dual node redundent storage array in capacities from 16 to 60 drives, design with HA, Replication and Clustering for the Enterprise.
Key Features: OptimStor 11.0.0.4 = arch: amd64 (64-bit) only
Full Web Management Interface
Current base system:
Base OS used for OptimStor series is HardenedBSD 11.0-RELEASE-HBSD
Primary Features
ZFS v5000 (Feature Flags)
ZFS LZ4- compression
Native ZFS Disk encryption (ComingSoon!)
Partition: MBR and GPT
Secure Vault
iSCSI initiator
Network Protocols supported:
NFS
S3
SWIFT
Clustering / Replication
Remote backup / restore
Cloud BackUp
Tarsnap integration
Webserver (lighttpd)
XEN Virtualization
Bhyve
Virtualized firewall / gateway VM
Extras:
FTP (ProFTPD)
TFTP (tftp-hpa)
RSYNC (client/server)
iSCSI target
Extra services:
Network Bandwidth measure tool (iPerf3)
RRDtool
Remote backup / restore
Cloud BackUp
Webserver (lighttpd)
XEN Virtualization
Bhyve
Networking:
802.1q vlan tagging
Wireless
Link aggregation
Wake On Lan
Bridge
CARP (Common Address Redundancy Protocol)
Monitoring:
System RRDGraphs and realtime system graphs.
S.M.A.R.T. (smartmontools)
E-mail alert
SNMP
Syslog
UPS (NUT)
Optional:
LSI SAS Controller
FiberChannel
Board Specifications:
Processor 6th Generation Intel® Core i7 / i5 / i3 / Pentium Processor
Socket LGA 1151 (Formerly Skylake)
Chipset Intel Q170
Memory 2 x SODIMM un-buffered Dual Channel DDR3L-1600 1.35V up to 16GB Total
Audio Intel® Display Audio
LAN 1 x Intel I219-LM PHY Gigabit LAN (iAMT 11.0)
7 x Intel I211-AT PCI-E Gigabit LAN
Storage 6 x SATA3 6Gb/s with RAID 0, 1, 5, 10 , JBOD
Super IO FINTEK F81768D-I
Back Panel Connectors
1 RJ45 Type Serial port
2 USB 3.0
1 RJ45 WAN (10/100/1000)
8 RJ45 LAN (10/100/1000)

Onboard I/O Connectors
1 PCI-E x4 Side-Slot, Supports Jetway ETC4G & ETC4B Expansion Modules
1 PCI Express Mini Card Slot (Full-size)
6 SATA3 6Gb/s Connectors
2 USB Pin Headers for up to 4 additional USB 2.0 Ports
1 SIM Card Holder
1 Chassis Intrusion Jumper
1 AT/ATX Mode Jumper
1 10-pin GPIO Header
1 19-pin HDMI Header
1 7-pin PS2 Keyboard Mouse Header
8 2-pin LAN LED Headers
1 9-pin Front Panel Header
3 4-pin Fan Headers
1 24-pin ATX Power Connector
1 4-pin 12V ATX Power Connector
How many devices do you have around the house? A cable or DSL router? A wireless device you bought? Maybe a USB hard drive for backups? A Multimedia Center? Our purpose is to converge all this into one device including a Secure Firewall, Virtualization Capabilities, Storage for Backups, Multimedia Capable All-in-one Appliance for the Home, or a system designed for the road warrior on the go.
Tired of the same old over priced products built for the 90s ? Missing the features that are required for todays market? Whannabe NAS boxes or copycats that all look the same and have the same feature sets.
Visit optimcloud.com to see more
Designed to be a storage system, with a virtual Firewall/Gateway for protection, and various NAS capabilities amongst other features that you want and need not found in whats available from other vendors today.
Primarily NFS and S3 capabilities, along with virtualization technologies that make it a very flexible device, compact, cloud compatible and secure
Available for pre-order soon! OptimStor - The next generation of virtualized secure NAS / S3...
Heres the SDL file view for the Road Warrior version, a thin portable all in one secure gateway firewall / NAS / backup device. Design to be portable enough to fit in your laptop bag and light enough to not push you over the carry-on weight limits.
for the OptimStor XS 3D printed case, To be our smaller portable road warrior version. Secure and protect your data and communications while on the road with a Firewall/Storage/Virtualization all-in-one appliance.
Our Enterprise Version is a HA design dual node redundent storage array in capacities from 16 to 60 drives, design with HA, Replication and Clustering for the Enterprise.
Key Features: OptimStor 11.0.0.4 = arch: amd64 (64-bit) only
Full Web Management Interface
Current base system:
Base OS used for OptimStor series is HardenedBSD 11.0-RELEASE-HBSD
Primary Features
ZFS v5000 (Feature Flags)
ZFS LZ4- compression
Native ZFS Disk encryption (ComingSoon!)
Partition: MBR and GPT
Secure Vault
iSCSI initiator
Network Protocols supported:
NFS
S3
SWIFT
Clustering / Replication
Remote backup / restore
Cloud BackUp
Tarsnap integration
Webserver (lighttpd)
XEN Virtualization
Bhyve
Virtualized firewall / gateway VM
Extras:
FTP (ProFTPD)
TFTP (tftp-hpa)
RSYNC (client/server)
iSCSI target
Extra services:
Network Bandwidth measure tool (iPerf3)
RRDtool
Remote backup / restore
Cloud BackUp
Webserver (lighttpd)
XEN Virtualization
Bhyve
Networking:
802.1q vlan tagging
Wireless
Link aggregation
Wake On Lan
Bridge
CARP (Common Address Redundancy Protocol)
Monitoring:
System RRDGraphs and realtime system graphs.
S.M.A.R.T. (smartmontools)
E-mail alert
SNMP
Syslog
UPS (NUT)
Optional:
LSI SAS Controller
FiberChannel
Board Specifications:
Processor 6th Generation Intel® Core i7 / i5 / i3 / Pentium Processor
Socket LGA 1151 (Formerly Skylake)
Chipset Intel Q170
Memory 2 x SODIMM un-buffered Dual Channel DDR3L-1600 1.35V up to 16GB Total
Audio Intel® Display Audio
LAN 1 x Intel I219-LM PHY Gigabit LAN (iAMT 11.0)
7 x Intel I211-AT PCI-E Gigabit LAN
Storage 6 x SATA3 6Gb/s with RAID 0, 1, 5, 10 , JBOD
Super IO FINTEK F81768D-I
Back Panel Connectors
1 RJ45 Type Serial port
2 USB 3.0
1 RJ45 WAN (10/100/1000)
8 RJ45 LAN (10/100/1000)

Onboard I/O Connectors
1 PCI-E x4 Side-Slot, Supports Jetway ETC4G & ETC4B Expansion Modules
1 PCI Express Mini Card Slot (Full-size)
6 SATA3 6Gb/s Connectors
2 USB Pin Headers for up to 4 additional USB 2.0 Ports
1 SIM Card Holder
1 Chassis Intrusion Jumper
1 AT/ATX Mode Jumper
1 10-pin GPIO Header
1 19-pin HDMI Header
1 7-pin PS2 Keyboard Mouse Header
8 2-pin LAN LED Headers
1 9-pin Front Panel Header
3 4-pin Fan Headers
1 24-pin ATX Power Connector
1 4-pin 12V ATX Power Connector
